Servo Motor Powered Speedy Plastic Card Puncher YLP-3 For 3*8 Layout
Speedy Plastic Card Puncher/Card Punching Machine/Card Die Cutter/Card Die Cutting Machine YLP-3
(Plastic card sheet puncher, plastic card puncher, card die cutter, card punching machine, card machine, card production machine)
1. Introduction of Servo Motor Powered Speedy Plastic Card Puncher YLP-3
It is applied for punching the laminated plastic sheets ( 3×7/3×8/3×10 layout) into ISO CR80 cards in a speedy and precise way.
2. Features of Servo Motor Powered Speedy Plastic Card Puncher YLP-3
- It applies high-quality PLC, touch screen and servo system in order to ensure the machine stability;
- The guide screws applied can well ensure the card conveying and punching precision.
- The reliable servo motor is applied as punching power to ensure more reliability and less failure ratio.
- The punching mould is specially designed to ensure perfect punching result and long-time service life.
| FREE SPARE PART LIST |
| SN | Part name | Part model | Qty. |
| 1 | Electromagnetic Valve | 4V110 | 1pc |
| 2 | Relay14PIN DC24V | MY4N-J DC 24V | 3pcs |
| 3 | Fuse | 10A | 5pcs |
| 4 | Fuse holder | RT18-32 | 1pc |
| 5 | synchronous belt | 10*200XL | 1pc |
| 6 | screw driver | | 1 set |
| 7 | Open spanner | | 1 set |
3. Technical sheet of Servo Motor Powered Speedy Plastic Card Puncher YLP-3
1).Power Supply: AC 380V/50 HZ
2).Material: Various plastic sheets including PVC, ABS, PETG, etc.
3).Total Power: 3.5KW
4).Material Size: 3X8, 4X8 or 5X8
5).Air Source: 6 kg/cm2(Dry)
6).Speed: 9000~12000 pcs /hr
7).Air Consumption: 70L/min
8).Control Method: PLC programming+ servo system
9).Weight: around 800Kg
10).Operator: 1 person
11).Precision: ±0.10mm
12).Dimension: L1700×W830×H1520mm
4. Application of Servo Motor Powered Speedy Plastic Card Puncher YLP-3
Speedy Plastic Card Puncher YLP-3 is also known or named as Card Punching Machine, Card Die Cutter or Card Die Cutting Machine YLP-3.
It is designed for A3+*( 3*8 layout )plastic card punching in semi-automatic way.
|
|
Servo Motor Powered Speedy Plastic Card Puncher YLP-3 For 3*8 Layout Images
|
